How to prevent collision of the swing barrier gate? In the development of anti-collision swing barrier gates, we fully consider that customers will inevitably encounter collisions during use, and specially design the anti-collision function of anti-collision swing barrier gates. Here we mainly introduce the characteristics of anti-collision:

1. Traditional swing barrier gates generally have no anti-pinch function. The anti-pinch function means that when the swing arm gate is opened, people will not get caught when they pass through the gate. The reason why people are caught is that they stay in and out for too long or they have carried some large luggage or items in and out of the gate, and when the person is walking forward and the luggage is behind, the swing barrier gate will recognize that the person has passed. The luggage behind was caught when the gate was closed. People or objects will be pinched. When the gate encounters resistance ≤ 3N.M, swing barrier gate will automatically slip, and the gate controller will issue an instruction (the gate is opened), and no one will be pinched at this time. It conforms to the humanized setting and meets the fire safety requirements.

2. Anti-collision and anti-clamping are different concepts. Anti-collision means that when the door is reset in place, under the condition of ≥15N.M suddenly under the action of external force, the gate will open immediately without hurting the movement and anti-collision pendulum bar, nor will it react, hurting people. It greatly improves the service life of the movement, and is generally used for passages such as bicycle lanes, tricycle lanes, and electric vehicle lanes.

3. When swing turnstile gate is opened suddenly under the force of external force, it also triggers the illegal intrusion alarm function to remind the staff.

4. After the anti-collision swing turnstile gate is opened by a strong impact, the staff can pull the anti-collision swing barrier gate back to the original position by hand or swipe the card or cut off the power. The operation is very convenient.

5. When the anti-collision function is not used, the upper and lower connecting plates can be locked, and this function is not available.
