Guangdong Lide Intelligence Technology Co., Ltd. is a high-tech enterprise with intelligent management products and services as its core. The company relies on the research and development, production, sales and service of pedestrian access gate management equipment, parking lot management equipment, intelligent door openers and other products to provide customers with comprehensive management solutions. Over the years, the company has been specialized in three-roll gates, swing gate turnstiles, drop arm turnstiles, full height turnstiles, access control systems, and parking lot systems.Integration and application, after continuous struggle and hard work, has now developed into a strong supplier of intelligent channel gate products in the industry.

One, the situation of a single core:

1. Put the chassis in a fixed position, and make the whole equipment in the best installation state.

2. Mark the center of the screw hole of the base and the edge of the chassis base on the ground, then remove the chassis, and use a drill to drill the marked screw holes vertically. The size and depth must meet the requirements of expansion screws.

3. Move the device to the original position, drive in the expansion screw and tighten the screw.

Second, the situation of double core:

1. If two swing gates are used in conjunction with each other, they should be debugged first, and then the case should be fixed to prevent the position of the case need to be fine-tuned during debugging.

2. First, power on the two swing gates to make the swing arms move to the closed state, and then align the swing arms of the two swing gates so that the swing arms are on the same line. The distance between the swing arms and the swing arms is 3CM to 5CM.

3. If infrared is installed, it is necessary to test whether the infrared is aligned or not. After all the functions are debugged, the case can be fixed after the end.

If you have any problem with the installation, our professional technics will help you.
