Item NO.:
LD-P404Payment:
TT / LC / Paypal / Western UnionProduct Origin:
ChinaColor:
SliverGoods stock:
100Shipping Port:
Guangzhou / Shenzhen PortLead Time:
7-10 DaysMotorized Slide Turnstile Speed Gate
The Motorized Slide Turnstile is typically used for pedestrian movement in factories, offices building, amusement parks, museums, and movie theatres etc. The Slide Gate is offered with a brushless DC motor for the movement of the swing baffles and can be integrated with varied access control systems.
The drive offer reach to 9 million cycles and is ideal for indoor application, however can be deployed outside a building under a shelter for protection from the natural elements.
LD-P404 Slide Turnstile offers the highest security for indoor application among all pedestrian gate with its full height barrier. The Gate is offered in both SS304 & SS316 versions.
Parameters:
|
Model No. |
LD-P404 |
|
Size |
1400*310*980 mm (L*W*H) |
|
Material |
304 stainless steel grades, Acrylic |
|
Channel width |
550mm |
|
Thickness of the outer box |
1.2 mm |
|
Input voltage |
AC100V ~ 240V, 50/60Hz |
|
Traffic direction |
Single or bidirectional |
|
Passing speed |
30~35 persons/minute |
|
Drive Type |
DC 24V Brushless Motor |
|
Life Time |
9 million times; |
Features:
* For functions of self-checking and audible alarms, it convenient for maintenance and daily use.
* Program operation mode of equipment through the built-in button inside the main board.
* Anti-rushing function: the door locks automatically if not receive the opening signal.
* To Adjust the gate to normal open or normal closed to meet the different requirements.
* Single way or bi-directional of traffic method.
* The gate can unlock in case of power failure and lock again when power recover.
* Automatic reset function: When the baffles retract into the cabinet, if people do not pass through within specified time, system will cancel the permission this time.
Leave A MessageSpeed turnstile gate use fast motors, beautiful appearance, fast opening speed, etc., suitable for corporate headquarters, high-end commercial buildings, high-end office buildings, interstellar hotels, etc.
The speed turnstile gate is directly driven by a motor to open the door quickly, which is very suitable for places with heavy traffic. And there is no noise, very suitable for office buildings, swimming pools, hotels, etc.
Modern design, faster pass speed, the speed gate is usually used at the high-end and crowded places such as clubs, smart buildings, villa communities, hotel lobbies, etc.
Low noise speed gate is the fast passage, especially suitable for places with with heavy traffic. It is glass turnstile gate, slim and modern desigan.
Speed gate is upgraded glass security swing turnstile which allows quick pass, always used as lobby entrance access control barrier gate in high traffic area . It is slim design, glass swing panel, It can be one -way or bi-direction passage, passage width and swing panel height can be customized made accordingly.
Speed gate is stylish glass swing turnstile gate with full stainless steel cabinet and fiber glass or acrylic sliding panel, it is created for access control with high requirements for design and passage’s comforts. Speed gate can provide fast, convenient contact-less passage.
CN Safety Gate Tech Speed gate offers high efficiency contact-less bi-direction passage. Integrated with access control system, speed gate allows authorized person quick pass, and prevent unauthorized passage. The design of speed gate combined the increasing technical requirement on the entrance gate but also the comfort of passage.
LD-S709 is a fast, streamlined speed gate with elegant design, it is made of 304 stainless steel with vacuum ion plating and anti-fingerprint treatment, which makes its flawless appearance.
