Full Height Turnstiles are an efficient and effective way to control and monitor the flow of people in and out of your facility.Single channel or dual channel can be customized.
Item NO.:
LD-Q808Payment:
L/C, T/TProduct Origin:
Made in ChinaShipping Port:
ShenzhenLead Time:
7-10 working daysLD-Q808 Security Entrance Full Height Turnstile Door Access Control System
Product Description :
The shape of the whole product is made by domestic standard 304stainless steel plate. The appearance is beautiful, rust-proof, durable, and can resist external damage. The passage formed by the rectangular case and the turnstile rod can provide an orderly and civilized way for people entering and exiting and also prevent illegal entry and exit. The product adopts advanced drive control technology, and the design can be changed to meet the various requirements of intelligent access control systems for different styles of modern buildings.
Product Parameters:
| Moduel No. | LD-Q808 |
| Size | 2280*1450*2200mm (length*width*height) |
| Material | 304 brushed stainless steel, 1.5mm thickness,no rust |
| Unlocking time | 1s |
| Traffic speed | ≤30 persons/min |
| Channel width | 550-650 mm |
| Input voltage | 220V, 50HZ |
| Drive voltage | 24V |
| Ambient temperature | -15~+55 degree |
| Power | 30W |
| Opening signal input | dry contact |
| Opening method | Push button, face recognition, RFID card reader, finger print |
Double Gates Full Height Turnstile Features :
1. The running status of the device can be programmed through the built-in small button on the main control board.
2. Unique bi-direction anti-reverse function.
3. Anti-shock function. When the gate didn’t received opening signal , the steel turnstile brake is automatically locked.
4. The full height turnstile is automatically unlocked after power off, and the function of free rotation meets the fire protection requirements. The door is automatically locked and closed after power is turned on.
5. It has an automatic reset function. After the gate is opened, if the pedestrian does not pass within the specified time,the system will automatically cancel the pedestrian's permission to pass . The reset time is adjustable from 1S to 60S (the system default time is 10S).
6. It can be integrated with various equipment such as access control system, consumer system, electronic ticket system, biometric system, electrostatic tester and so on.
7. The entry and exit of people can be controlled single direction or bi-direction.
8. Remote control and management can be realized directly through the management computer.
Expandable function :
1. LED count display function.
2. The chassis is lengthened and the shape is optional.
3. Normally open or normally closed channel adjustment to meet the different venues requirements.
4. Compatible with bar code/QR code scanning, ID card reading, fingerprint recognition, etc.
Product certifications:
