Flap Turnstile is designed for use in applications with high volume pedestrian traffic that require rapid access and ensuring the high level of security.
Item NO.:
LD-Y605Payment:
TT / LC / Paypal / Western UnionProduct Origin:
ChinaColor:
SliverGoods stock:
100Shipping Port:
Guangzhou / Shenzhen PortLead Time:
7-10 DaysHigh Speed Flap Barrier Gate Turnstile
The flap barrier is controlled by a programmable logic controller (PLC) which is compatible with all kind of access control systems and the electronic mechanism is enclosed in a high quality 304 stainless steel cabinet. The barrier dimensions, housing material as well as shape make the device looks gentle and light.
The passageway length is 900mm which is allow the people with wheelchairs (International standard) to through and the closing force on the flap is monitored electronically preventing injury to pedestrians. It can be used in office building, hotel and apartment building.
Parameters:
|
Model No. |
LD-Y605 |
|
Size |
1400*310*980 mm |
|
Material |
304 stainless steel, PU |
|
Lane width |
900mm |
|
Thickness of the housing |
1.2mm / 1.5mm |
|
Drive motor |
Brushless DC 24V |
|
Input voltage |
220V, 50HZ |
|
Passing speed |
30-35 people / minute |
|
Opening signal |
Dry contact |
|
Life |
9 million times; |
Features:
1. The high speed gate turnstile can alarm and close quickly when someone enter from the opposite direction.
2. Can be configured for single direction or bi-directional passage.
3. The illuminated symbols clearly indicate if the visitor authorized and also show if the lane is clear to go through.
4. System runs smoothly, low noise, no mechanical impact.
5. The flap turnstile alarms if someone wants to break in without permission
6. Flap arms will open automatically in case power failure, which is complying with fire safety requirements
7. It equipped sensitive Infrared sensor for improving the accuracy of detection.
8. It can link to all brands of door access control system and biometric recognition system.
9. It will lock automatically within 5s (can be setting) if passenger delay to entry.
Leave A MessageThere are many advantages of flap barrier wing gate. First: The speed of opening door is high. Second: Safe. Third: Simple maintenance.
ESD access control speed gate flap barrier is fast opening turnstile gate with ESD detection, which are widely used in electronic industry as entrance & exit gate. It helps electronic factory to eliminate static electricity interference and realize employee attendance.
Flap barrier turnstile is a kind of barrier gate with beautiful appearance, fast passing speed, and extremely effective for personnel verification.
Made of austenitic stainless steel (SUS304), with high mechanical resistance, corrosion resistant, excellent hygiene and cleanliness factor, elegant design and great durability.
Flap turnstile is optical automatic entrance gate used in modern buildings to restrict personal access, especially the commercial office towers with high pedestrian flow requirement. The access control flap turnstile allows authorized entrant and block UN-authorized entry, it is a advanced and touch-less, unattended equipment to manage traffic in your buildings.
Flap barriers are cost-effective and space-saving entrance gates, normally used at commercial and industrial places to control the pedestrian flow, such as subway station, museum, school.
Flap Barrier is the entrance access system which would allow the employees and identified visitors pass the gate quickly. This is the good solution of building security management.
Retractable Flap Barrier is designed to solve the common issue which happened in commercial buildings and other facilities like quick pass of employees and visitors, protect facility property.
