The swing gate turnstile organically integrates mechanical, electronic, microprocessor control and various reading and writing technologies, and adopts a standard electrical interface to the outside, it can facilitate system integration of reading and writing devices such as magnetic cards, barcode cards, ID cards and IC cards.
Item NO.:
LD-B524Payment:
TT / LC / Paypal / Western UnionProduct Origin:
ChinaColor:
SliverGoods stock:
100Shipping Port:
Guangzhou / Shenzhen PortLead Time:
7-10 DaysSWING GATE TURNSTILE ACCESS CONTROL TURNSTILE GATES
The LD-B510 swing turnstile with RFID card reader is made of 304 stainless steel by stamping and forming, which is rust-proof, strong and durable. The equipment is simple to use and maintenance-free.
Provide a civilized and orderly way for people entering and exiting, and at the same time prevent illegal people from entering and exiting; the system is also specially designed to meet the fire protection requirements, so that in an emergency, the passage is unblocked to ensure the smooth evacuation of personnel.
Specifications:
|
Size |
1540*185*1020 |
|
Material |
304 stainless steel, acrylic |
|
Channel width |
standard 1200mm (<1200mm can be customized) |
|
Thickness of the outer box |
1.5mm+1.2mm |
|
Drive motor |
DC 24V brushless motor, low noise |
|
Control panel |
one for one |
|
Traffic direction |
one-way traffic/two-way traffic; |
|
Passing speed |
35~40 persons/minute |
|
Opening methods |
ID/IC card and other readers verify opening, infrared induction automatic opening, button opening, etc. |
|
Opening signal |
dry contact signal |
|
Protection functions |
electromechanical anti-collision, infrared anti-clamping, infrared alarm for illegal intrusion |
|
Life |
9 million times; |
|
Infrared quantity |
6 pairs |
Applications:
It is suitable for one-way or two-way access control system of the entrance and exit channels of the flow of people.
*Import and export channels of stations, wharfs and tourist attractions
*Ticket inspection channels for exhibitions, swimming pools, etc.
*Import and export attendance, access control, consumption management of communities, schools, factories, enterprises and institutions
*Special channel control
*Suitable for bicycles, motorcycles, and disabled access
Leave A MessageThe swing turnstile is an intelligent management device designed to restrict or control access to buildings or safe areas.
LD-B509 swing barrier turnstile is an intelligent channel, which could integrate multi opening way, such as IC card, ID card, QR code, fingerprint, face recognition devices.
CN Safety Gate Tech is a professional manufacturer of intelligent swing gates for supermarket entrances, safe and stable, customized solutions according to needs, logos and welcome messages can be customized.
Automated swing turnstile gate for handicap, it is the swing turnstile with wide passage at least 800-1000mm , which allows wheelchair to pass in bi-direction. This kind of turnstiles are always required together with standard passage width 600mm turnstile and used in public commercial buildings. Also delivery man or pedestrian with large packages can use this channel.
Drop arm barrier turnstile is made of stainless steel #304, brushed surface treatment, dust-proof, rustproof, rainproof design, suitable for indoor and outdoor use.
Swing barrier gate has the most widely applications with its wider channel width.
The use of swing gates can make people flow through the passage in an orderly manner.
The swing turnstile is the half height automatic entrance, with different kind of sensor controlled component, it would be suitable for access management and keep the safety of an area.
